/TS-BC25RM Type 1+2 Lightning Current & Surge Arrester

WARNING

1. The device must be installed by electrically skilled person, conforming to national standards & safety regulations.

2.  It is recommended that installation should be done under power off condition.

TSTLP®/TS-BC25RM Type 1+2 Lightning Current & Surge Arrester

TS-BC25RM series Type 1 lightning current & surge arrester, designed according to IEC / EN 61643-11 & GB 18802.11 is for installation at LPZ 0A -2 or higher, protecting low voltage equipment against lightning and surge damages. Applied SPD Modular in Class I+II (Class B+C) for various power supply system.

Similar & Related Power Supply Surge Protectors

TS-BC25RM(3+N) Class B+C Lightning Current & Surge Arrester
  • Product Name :

    TS-BC25RM(3+N) Class B+C Lightning Current & Surge Arrester

Instruction

TSTLP®/TS-BC25RM Type 1+2 Lightning Current & Surge Arrester

TS-BC25RM series Type 1 lightning current & surge arrester, designed according to IEC / EN 61643-11 & GB 18802.11 is for installation at LPZ 0A -2 or higher, protecting low voltage equipment against lightning and surge damages. Applied SPD Modular in Class I+II (Class B+C) for various power supply system.

Similar & Related Power Supply Surge Protectors

TS-BC25RM3N-Class-BC-Lightning-Current-amp-Surge-Arrester-Price

TS-BC25RM3N-Class-BC-Lightning-Current-amp-Surge-Arrester-Price

♦ Technical Data

Type (1+2) TS-BC25RM [ L/N] TS-BC25RM ( N/PE )
Nominal voltage ( 50/60Hz )Un230V / 400~
Rated voltage (max. continuous voltage)Uc320V~255V ~
Lightning impulse current (10/350)Iimp12.5kA37.5kA
Nominal discharge current (8/20)In30kA50kA
Max. discharge current  (8/20)Imax65kA100kA
Total discharge currentItotal100kA
Voltage protection level at @ 320VUp≤ 1.8kV≤ 1.5kV
Residual voltageUres1.35kV @ Iimp
Follow CurrentIf1000A
Specific EnergyW/R39.06kJ/Ohms351.56kJ/Ohms
Response timetA≤ 25ns≤ 100ns
Degree of protection (by the enclosure)IP20
Temporary Over-voltage Test ValueUT355V/5sec
Number of ports1-Port
Installation Position CategoryInaccessible
Method of mountingFixed
Presence of Switching Component(s)N-PE
Prospective Short-circuit current1A
Dielectric withstand3000V
Admissible Short-CurrentIsccr25kA
Orientation for normal installationIndoor
Max. back up fuse [F]160A gL/gG
Operating temperature range [Tu]Tu-40°C…+80°C
Cross-sectional area1.5mm2 ~ 25mm2 solid /35mm2 flexible
Mounting on35mm DIN rail
Enclosure materialLight Grey thermoplastic, UL94-V0
Dimension1 mod
StandardsIEC 61643:11 & GB 18802.11
Type of remote signalling contactSwitching contact
Switching capacityUN/INAC:250V/0.5A; DC:250V/0.1A;150V/0.2A;750V/0.5A
Cross-sectional area for remote signalling contactMax. 1.5mm2 solid / flexible
ComplianceCE (LVD, EMC & RoHS)


♦
 MAIN CHARACTER

1. 10/350, 8/20ps varistors

2. Consist of varistor and thermal disconnection device

3. High discharge capacity, quick response, pluggable

4. Double thermal disconnection devices, providing more reliable protection

5. Multifunctional connection for conductors and busbars

6. Green window will change to red when fault and also provide remote alarm control at the same time

INSTALLATION INSTRUCTION

According to lightning protection zones concept, for installation at LPZ 0A -2 or higher. It is usually installed in floor distribution-box or ClassⅠmain distribution-box

Fuse must be installed at the upstream of the SPD or the surge protector to make sure that protected system has double protection. The value of the fuse used in a SPD system should be conformed to:

1. The value of FUSE should not be larger than the max.withstand capacity of the SPD’s backup fuse value.

2. Under the status of the max. current in the power supply & close loop circuit available current, the fuse should be able to disconnect when overloaded or short-circuited.

Take 1 & 2 into consideration, the fuse should be as large as possible to allow the maximum surge discharge of SPD.

INSTALLATION STEPS

1) Check the product for integrity of the package; make sure the product window indicates green.

2) Mount the SPD on 35 mm DIN rail.

3) Connect conductors, the cross-sectional area of cable must be larger than 16mm2 . The withstand voltage value of cable is not smaller than AC500V; ensure wiring reliable.

4) If need remote alarm, it should be connected signal lines to remote signal terminal 1 and 2, or 2 and 3 (When normal,1 and 2 open, 2 and 3 close; when fault, the state is reversed).

5) Remote Contact: When the Green window display RED, 1 & 2 are connected; And the extra light will be on if the both terminals are connected with light.

6) After above, switch on the power supply and turn on the circuit breaker,if the SPD’s window does not appear red, this indicates the unit is operating normally.

Regularly inspect the operating status, especially after lightning. Once the fuse upstream break, or the SPDs fault appear, electrician should check/replace the SPD.

 INSTALLATION DIAGRAM (3+1)
